Intelligent drive drum with permanent magnets
Jasung presents a unique external rotor technology with permanent magnets. In the Jasung intelligent permanent magnetic drum, the shaft is a fixed part, similar to the stator of an electric motor. The stator iron core consists of layers of silicon steel fixed to a shaft inside which the stator winding is located. When a symmetrical three-phase alternating current is applied to the stator winding, a rotating magnetic field is created.
The surface of the drum is similar to the rotating part of the electric motor and consists of layers of silicon steel fixed on the inner surface of the drum. Inside it are magnets made of high-strength material of UH class. These magnets create a constant magnetic field, and when a symmetrical three-phase alternating voltage is applied, the machine starts working, and therefore the drum also works.
Download the questionnaire
consult
High reliability
Equipment Features
Unique permanent magnet technology
Multi-mode direct drive technology
Power in all operating ranges
Low inrush current
High energy efficiency
Innovative external rotor technology
Compactness
Drum gear
High level of system efficiency
Low noise level
Advantages of technology
Consult
it is provided by a simple system
without gears and other mechanical gears and a large (in comparison with the classic) low-speed bearing.
only updating the lubricant every 2000 hours of operation.
from the moment of start-up, the rated torque is provided; maximum permissible 3-fold overload (depending on the order).
the ability to start the drum at low current, the linear dependence of the current on the load.
the best power/size ratio, in comparison with the traditional system. It does not require a large mounting chamber and a bulky foundation, which significantly reduces infrastructure costs.
90%-95%
about 70 Db.
up to 30%
energy consumption is 20−30% less, in comparison with classical technology
Minimum costs and maintenance costs
Energy saving
